Wall Switch Plate Flow Wrapping Machine

Decorative wall switch plates are flat, regularly shaped products that can be individually protected in horizontal pillow packs. This application concerns the decorative faceplate only—not an electrical outlet, socket, switch mechanism or energized component.

Illustrative packaging example

Published HYS Configuration Facts

• HFFS model range: HFS-260, HFS-350 and HFS-450
• Published speed range: 20–250 packs/min
• Published finished bag widths: 25–110, 25–150 and 50–200 mm by model
• Published suitable film thickness: 0.03–0.06 mm

Final model, options and output are confirmed from product and package samples.

Custom functions: Nitrogen flushing, dust extraction, metal detection and checkweighing require a customized machine or line configuration.

Protecting Decorative Surfaces

• Provide plate length, width, thickness, material, finish and acceptable contact points.
• Guides and flights should maintain orientation without scratching painted, polished or brushed surfaces.
• Protective film, interleaf or tray requirements must be defined before selecting the infeed.
• Sharp corners and raised decorative features should be checked against the film and forming path.

Film and Seal Configuration

• Confirm transparent or printed film, thickness, friction and required scratch protection.
• Bag dimensions should prevent excessive movement while leaving the end-seal area clear.
• Eye-mark control is required when printed artwork must align with the faceplate.
• The forming box and guide set may require change parts for different plate dimensions.

Production Inputs for Selection

• Every faceplate size, finish and target package dimension.
• Manual placement, indexed conveyor or upstream automatic supply method.
• Required good packs per minute, film roll and seal acceptance criteria.
• Coding, labeling, grouping and downstream carton-loading requirements.
